LED transparent screens have been widely used in commercial display fields such as curtain walls and shop windows. The transparent and gorgeous images bring a high-tech and cool visual experience, so they are becoming more and more popular. Especially the curtain wall LED transparent screen, which is hundreds of square meters at every turn, so is the full-color LED transparent screen spliced? Or how to install, let's take a look at this question:

Whether it is a conventional large LED screen or a transparent LED screen, it is actually a piece of box spliced together. Each box usually has a fixed size. The most common size in the industry is 1000mm × 500mm, that is, the area of a single box is 0.5 square meters. Here is an example for easy understanding:

The customer customized the window transparent screen in Lianman Optoelectronics, the screen is 8 meters long and 5 meters wide. The size of the cabinet is 1000mm×500mm, then 8 cabinets are required for the length and 10 cabinets for the width, and a total of 80 cabinets are required to splicing this large screen.

So some people must be curious, why not make a whole screen, or make the box bigger, isn't that bad? In fact, these have been considered for a long time, and it will not work. Because the box is too large, the weight will increase, it is inconvenient to move and transport, and it is also inconvenient to install. More importantly, it becomes very difficult to maintain later. Therefore, comprehensive consideration, the current LED transparent screen box area is generally controlled within 0.2~1 square meters. If the box is customized for special occasions, the area will be larger, but generally not more than 3 square meters.

Therefore, the LED transparent screen is spliced. Let's continue to see how to install the LED transparent screen. According to the common installation methods, we will briefly introduce them. There are usually three ways of hoisting, fixed and seated:

1. Hoisting: The screen body is installed by hooks and hanging beams, and the transparent screen boxes are connected by quick locks or connecting pieces; it is used in the fields of stage, window shop, etc.

2. Fixed installation: The box frame is fixed on the glass curtain wall keel by combining hoop parts or composite bolts; it is used in the field of architectural glass curtain walls;

3. Seat installation: The transparent screen box is fixed on the Japanese frame through the connecting piece; it is used in exhibition halls, auto shows, press conferences and other fields;

Regardless of the installation method of the above transparent LED screen, it is necessary to ensure that the splicing between the cabinets is flat, and the seam is controlled within 1mm to ensure the normal playback of the display effect. During the installation process, it is also necessary to ensure the safety of the installation environment. If it is a high-altitude operation, take appropriate measures to restrict the activity area and prompt guidance, and take safety measures such as wearing a safety helmet.
